7 AJA R20CE 10-bit Encoder User Manual
Bank 1 (Frame Sync Option Only)
FUNCTION DESCRIPTION DETAILS
0 BANK SEL Toggle UP/LEFT to select BANK I
Toggle DOWN/RIGHT to select BANK 0
| SET DEFAULT
DELAY
Toggle UP/LEFT or DOWN/RIGHT =
Restores FSC to factory defaults
2 SET LINE DELAY Toggle UP/LEFT = increases
OutputDelay by lines
Toggle DOWN/RIGHT = Decreases
Output Delay by lines
3 SET PIXEL DELAY Toggle UP/LEFT = increases Output
Delay by pixels
Toggle DOWN/RIGHT = Decreases
Output Delay by pixels
4
5
6
7
8
9
A
B
C
D
E STORE/RECALL
USER
CONFIGURATION Toggle UP/LEFT to Store Register
Toggle DOWN/RIGHT to Recall Register
F RESTORE
DEFAULTS Toggle UP/LEFT or DOWN/RIGHT to
Restore Default Settings
