AJA R20CE 10-bit Encoder User Manual

Specifications

Item

Specification

Input Format:

SMPTE 259 / ITU-R-601 Serial Digital Component

Primary Output Format:

NTSC, PAL, Y/C (S Video)

Active Looping Output:

SMPTE 259 / ITU-R-601 Serial Digital Component

Reference Input Format:

NTSC or PAL Analog Color Black

SDI Cable Equalization:

300 meter 8281 typical

Serial Output:

Equalized, Re-clocked

Return Loss:

Serial Input:15 dB to 300MHz,
Serial Output:15 dB to 300MHz

FrequencyResponse:

+/- 0.25dB to 5.5MHz (Y)
+/- 0.25dB to 2.0Mhz (Chroma - Component, RGB)
+/- 0.25dB to 1.3Mhz (Chroma - Composite)

2T K factor:

<1% (Y)

Diff. Gain:

<1.5%

Diff. Phase:

<1.5 degree

Y/C delay:

l0 ns max

D/A Converters:

10 bits

Signal Path:

l0 bits

Delay (input to output):

6.2 microseconds (without Framesync option installed)

Output level matching:

1.5% or l0mv (All outputs are separately buffered)

Output level adjustment:

+/-20% (internal)

Power Consumption:

6.0 W (w/o FSG Framesync)
7.5 W (w/ FSG Framesync)
