Bank 0 Functions
FUNCTION DESCRIPTION DETAILS
0 BANK SEL ToggleUP/LEFT to select BANK 1
Toggle DOWN/RIGHT to select BANK 0
1 |NPUT MODE 0 = Auto Select
1 = 525
2 = 625
2 VBLANK UP/LEFT = Narrow
DOWN/RIG HT = Wide
3 SETUP UP/LEFT = No Pedestal
DOWN/RIGHT=AddPedestal
4 OUTPUT MODE 0 = Composite on all
1 = Y,Pb,Pr
2 = RGB
3 = Y/C
5 COMPONENT
LEVELS UP/LEFT = BETACAM 525 (Y, R-Y,B-Y)
DOWN/RIGI[T = SMPTE EBU N-10/
BETACAM 625 (Y,Pb,Pr)
(When OUTPUT MODE = Y,Pb,Pr)
6 INPUT SOURCE Toggle DOWN to pass video.
Toggle UP for Bars (Internal test signal)
7
8 CLEAR USER
SETUP Toggle either way to clear User EEPROM
and reset board
9 RESET Toggle either way to reset board
A
B
C
D
E STORE/RECALL Toggle UP to store register
Toggle DOWN to recall register
F RESTORE
DEFAULTS Toggle either way to restore default settings
