AJA FS1 Version 2.2.2.1 - Manual (Page 90)

80
Video In (2.1)
NTSC Standard (3.4)
Audio In (2.2)
Frame Rate (3.3)
Component In (3.1)
Component Out (3.2) Signal Type
Analog Audio Standard (4.1)
SDI 1 (default)
SDI 2
Composite
S-Video
Component
Select SDI 1 connector as the input source.
Select SDI 2 connector as the input source.
Select the Composite connector as the input source.
Select the S-Video connector as the input source.
Select the Component connector as the input source.
NTSC (default)
NTSC Japan
Select NTSC for US NTSC standard.
Select NTSC Japan for the Japanese NTSC standard.
Embed Auto
(Follows Video Input select)
Embed SDI 1
Embed SDI 2
AES unbal (default)
Analog
Use the embedded audio from the currently selected Video Input (SDI 1 or 2) as the input
source. (This defaults to SDI 1 if Video In is not SDI.)
Use the embedded audio from the SDI 1 connector as the input source.
Use the embedded audio from the SDI 2 connector as the input source.
Select thedigital AES/EBU Audio connectors (8-ch) as the audio input source.
Select the Analog Audio connector (DB25, 8-ch) as the audio input source.
59.94/23.98 (default)
60/24
50/25
Select the 59.94/23.98 item if your desired rate is either 59.94 or 23.98.
Select the 60/24 item if your desired rate is either 60 or 24.
Select the 50/25 item if your desired rate is either 50 or 25 (PAL).
Beta YPbPr
SMPTE YPbPr (default)
Configure the Component video input source as Beta YPbPr (standard definition). If the
selected Component video source is HD, this will default to SMPTE YPbPr.
Configure the Component video input source as SMPTE YPbPr.
Beta YPbPr
SMPTE YPbPr (default)
RGB
Configure the Component video output as Beta YPbPr (standard definition). If the
Component video is HD, this will default to SMPTE YPbPr.
Configure the Component video output as SMPTE YPbPr.
Configure the Component video output as RGB.
+24 dBu (default)
+18 dBu
+15 dBu
+12 dBu
Select +24 dBu as the analog audio level.
Select +18 dBu as the analog audio level.
Select +15 dBu as the analog audio level.
Select +12 dBu as the analog audio level.
Maximum amplitude (0 dBFS)
