SPECIFICATIONS
Heating Capacity and Efficiency
30040
30060
42060
48080
60080
42100
60100
60120
60140
Input
High
Heat
(BTUH) 40,000
60,000
60,000
80,000
80,000 100,000 100,000 120,000 140,000
Output
High
Heat
(BTUH) 39,000
58,000
58,000
78,000
78,000
97,000
97,000 117,000 135,000
Efficiency
AFUE % (ICS)
95.5
95.5
95.5
95.5
95.5
95.5
95.5
95.5
95.5
Certified Temperature
Rise Range ºF (ºC)
High Heat
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
40 - 70
(22 - 39)
45 - 75
(25 - 42)
Airflow Capacity and Blower Data
30040
30060
42060
48080
60080
42100
60100
60120
60140
Certified External Static
Pressure (in. w.c.)
Heating
0.10
0.12
0.12
0.15
0.15
0.20
0.20
0.20
0.20
Cooling
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Airflow Delivery
@ Rated ESP (CFM)
High Heat
820
840
980
1040
1500
1565
1520
2210
2190
Cooling
905
1130
1420
1600
2025
1565
2145
2065
2100
Cooling Capacity (tons)
@ 400, 350 CFM/ton
CFM/ton
2
2.5
3.5
4
5
4
5
5
5
CFM/ton
2.5
3
4
4.5
5.5
4.5
6
6
6
Direct-Drive Motor Type
Permanent Split Capacitor (PSC)
Direct-Drive Motor HP
0.5
0.5
0.5
0.75
0.75
0.75
0.75
0.75
0.75
Motor Full Load Amps
6.2
6.2
6.8
7.9
13.8
6.5
13.8
14.1
14.1
RPM Range
500-1150
Speed Selections
4
4
5
5
5
5
5
5
5
Blower Wheel Dia x Width
in. 11 x 7
11 x 7
11 x 8
11 x 8
11 x 10 11 x 10 11 x 10 11 x 11 11 x 11
Air Filtration System
Field Supplied
Filter Used for Certified Watt Data
KGAWF1606UFR
KGAWF1306UFR
KGAWF1406UFR
KGAWF1506UFR
Electrical Data
30040
30060
42060
48080
60080
42100
60100
60120
60140
Input Voltage
Volts-Hertz-Phase
115-60-1
Operating Voltage Range
Min-Max
104-127
Maximum Input Amps
Amps
6.8
7.0
8.4
9.6
14.5
7.6
14.6
14.9
14.9
Unit Ampacity
Amps
9.5
9.7
11.5
13.0
19.1
10.4
19.2
19.6
19.6
Minimum Wire Size
AWG
14
14
14
14
12
14
12
12
12
Maximum Wire Length
Feet
39
38
32
28
30
35
29
29
29
@ Minimum Wire Size
(M)
(11.9)
(11.6)
(9.8)
(8.5)
(9.1)
(10.7)
(8.8)
(8.8)
(8.8)
Maximum Fuse/Ckt Bkr
(Time-Delay Type Recommended)
Amps
15
15
15
15
20
15
20
20
20
Transfomer Capacity (24vac output)
40 VA
External Control Power Available
Heating
27.9 VA
Cooling
34.6 VA
Controls
30040
30060
42060
48080
60080
42100
60100
60120
60140
Gas Connection Size
1/2" - NPT
Burners (Monoport)
2
3
3
4
4
5
5
6
7
Gas Valve (Redundant)
Manufacturer
White Rogers
Minimum Inlet Gas pressure (in. wc)
4.5
Maximum Inlet Gas pressure (in. wc)
13.6
Gas Conversion Kit - Natural to Propane
KGANP50011SP
Gas Conversion Kit - Propane to Natural
KGAPN42011SP
Manufactured (Mobile) Home Kit
KGAMH0601KIT
N/A
Ignition Device
Silicon Nitride
Limit Control
165
165
180
170
200
180
180
160
155
Heating Blower Control (Heating Off-Delay)
Adjustable: 90, 120, 150, 180 seconds
Cooling Blower Control (Time Delay Relay)
90 seconds
Communication System
none
Thermostat Connections
Com 24V, R, W, G, Y
Accessory Connections
EAC (115vac); HUM (24vac)
