Weidmuller PTX800D - Scalable pulse and frequency counter - Manual (Page 11)

General alarm settings
Setpoint
security
SECure_y
SECure_n
Setpoints fixed at setup
Can change setpoints
Toggle Accept
Alarm reset
sequence reS_Auto
rES_Oper
Automatic reset
Manual reset
Toggle Accept
Analogue output settings (not shown unless outputs are fitted)
Rate or total
output
Out=rate
Out=_tot
Analogue output proportional to rate
Analogue output proportional to total
Toggle Accept
Rate range
represented
rate_LO=
0.00
Introduces the rate low value
e.g., 0.00 -
Dec
-
Inc
Next
Accept
rate_HI=
100.00
Introduces the rate high value
e.g., 100.00 -
Dec
-
Inc
Next
Accept
Total range
represented
tot_LO=
0.00
Introduces the rate low value
e.g., 0.00 -
Dec
-
Inc
Next
Accept
tot_HI=
100.00
Introduces the rate high value
e.g., 100.00 -
Dec
-
Inc
Next
Accept
Output type
Out=_Cur
Out=volt
Current (mA) output
Voltage (V) output
Toggle Accept
Output range
Out_LO=
4.00
Introduces output low value
Value, e.g., 4.00 mA -
Dec
-
Inc
Next
Accept
Out_HI=
20.00
Introduces output high value
Value, e.g., 20.00 mA -
Dec
-
Inc
Next
Accept
Output Action
Out_dir
Out_rev
Direct (proportional) output
Reversed (inverted) output
Toggle Accept
Calibration options
Calibrate
Output?
CalOut_n
CalOut_y
Skip output calibration
Calibrate outputs
Toggle Accept
Display
Intensity Intens_=
234567.89
Introduces the display intensity
Demo display for adjustment -
Dec
-
Inc
Next
Accept
Save values SAVE
Instrument is saving the changes to the setup and returning to
normal operation
Setup Sequence (continued)
