Page 8

1
Note: the analogue output calibration sequence is not shown if the
analogue output is disabled.
You can calibrate each stage in sequence or skip sections by pressing
the PGM button.
Whenthe
displayshows
Action/Description
Put the instrument in setup mode and scroll through the main menu
CALIB
Press
ENT to enter calibrate mode
ECALn
Press
ì or Å and then ENT to select millivolt input calibration (or PGM to skip)
E=0
Apply a 0.00 mV signal and press
ENT
E=10
Apply a 10.00 mV signal and press
ENT
E=20
Apply a 20.00 mV signal and press
ENT
E=40
Apply a 40.00 mV signal and press
ENT
E=80
Apply a 80.00 mV signal and press
ENT
E=200
Apply a 200.00 mV signal and press
ENT
jCALn
Press
ì or Å and then ENT to select CJC input calibration (or PGM to skip)
CJ=0
Apply a 0.00 mV signal to the CJC input and press
ENT
Cj=60
Apply a 600.0 mV signal and press
ENT
rCALn
Press
ì or Å and then ENT to select Rtd input calibration (or PGM to skip)
-200C
Set the RTD simulator to -200 ˚C and press
ENT
0C
Set the RTD simulator to 0 ˚C and press
ENT
400C
Set the RTD simulator to 400 ˚C and press
ENT
800C
Set the RTD simulator to 800 ˚C and press
ENT
OCALn
Press
ì or Å and then ENT to select analogue output calibration (or PGM to skip)
I=0
Measure the current (mA) output.
Adjust using the
ì and Å keys until the output is at 0.00 mA.
Press
ENT.
I=20
Adjust using the
ì and Å keys until the output is at 20.00 mA.
Press
ENT.
E=0
Measure the output voltage.
Adjust using the
ì and Å keys until the output is at 0.00 V.
Press
ENT.
E=10
Adjust using the
ì and Å keys until the output is at 10.00 V.
Press
ENT.
CALIB
You are now back in the main menu, press
PGM
SAvE
Instrument will save the new values and return to run mode
