PMX400/TMP
•Operation
Warning:Checkthepowersupplyagainstthemodelnumberbeforeapplying
powertotheinstrument.
Reviewingthesetup
For review mode, disconnect security link and press PGM.
A 10 s timeout applies for review mode.
Changingthesetup
For setup mode, connect security link and press PGM. The software
version will be displayed. If you wish to continue, press PGM again
within 10 s.
Clearingtrippedalarms
You can acknowledge a tripped alarm by simply pressing the key for
that channel.
Temperature
Sensor Inputs
Analogue Output
(Optional)
Alarm 3
Alarm 4
Alarm 1
Alarm 2
(Optional)
(Optional)
Power
Supply
°C, °F or mV
