E. INSTALLING THE HANDLE
1. Unscrew the handle holders from the handle assembly (#6).
2. Place the handle to the position on the door. Place plastic washers (supplied) on each side
of the door. [SEE FIG.12]
3. Tighten the handle nuts from inside the shower.
F. INSTALLING THE WATER SEAL STRIP
1. Place the seal strip (#13) to the door and to the fixed panel, respectively. [SEE FIG.13]
2. Trim the flange on the seal strips so that there is enough clearance for the door to roll
without the seal strips hitting against the rollers or door stopper.
9
MODEL VG06041
8
9
FIG. 11
FIG. 12
