MODEL VG06041
WALL OUT OF
PLUMB
WALL
TOP ANGLED WALL
A B TILTS IN AT TOP
(EXAGGERATED
FOR PURPOSE
OF DEPICTION)
FIG. 3
The small hex
hole on on the
roller will be
facing up on this
roller.
ROLLER (3)
The small hex
hole on on this
roller will be
adjusted to meet
the gap.
ROLLER (3)
ROLLER "A"
SMALL HEX HOLE
DIRECTION
ROLLER "B"
SMALL HEX HOLE
DIRECTION WALL DIRECTION
TOP ANGLED UP ADJUST AS NEEDED
