Vigo VG06041 - Manual (Page 3)

1. WALL MOUNT
BRACKET ASSEMBLY 2. FIXED PANEL HOLDER
4. FIXED PANEL
6. HANDLE ASSEMBLY 7. FIXED PANEL BOTTOM
CLIP 8. DOOR BOTTOM
GUIDE 9. DOOR THRESHOLD
11. STRUCTURAL RAIL 12. DOOR AND FIXED
PANEL SEAL STRIP
3. ROLLERS
10.DOOR STOPPER
A
13. DOOR SEAL STRIP
5. DOOR
MODEL VG06041
C
14. THRESHOLD
EXTENSION CLIP
B
15. PHILLIPS SCREW 2"
PLASTIC ANCHOR 16.
98018 98019 98020
97015-48x74
97015-60x66
97015-60x74
97015-72x74 97016-48x74
97016-60x66
97016-60x74
97016-72x74
98021 98022 98023 95005-48
95005-60
95005-72 98024
98025 96001 96013 95006 98036
3
98037
PLASTIC ANCHOR 17.
PHILLIPS SCREW
1 1/8" 18.
98035
98038
adjustment on bottom, make
sure it is set to 10mm or 3/8"
A, B & C DIMENSIONS WERE MEASURED AFTER SHOWER ENCLOSURE WAS
COMPLETELY INSTALLED
DIMENSION "B"
(FIXED PANEL) DIMENSION "A"
(DOOR)
25 5/8" x 73 3/4" 23 5/8" x 74"
HEIGHT
74"
LIST
DIMENSIONS
48X74
60X74
60X66
72X74
ADJUSTABLE
DIMENSION "C"
(WIDTH)
44"-48"
29 5/8" x 74" 74" 56"-60"
66" 56"-60"
31 1/2" x 73 3/4"
31 5/8" x 65 3/4"
29 5/8" x 66"
74" 37 1/2" x 73 3/4" 35 5/8" x 74" 68"-72"
THE CORRESPONDING VIGO BRAND BASES ARE AS FOLLOWS:
MODEL VG06049WHT4832C - MODEL 48X74
MODEL VG06049WHT4836C - MODEL 48X74
MODEL VG06049WHT6030C - MODEL 60X74
MODEL VG06049WHT6032C - MODEL 60X74
MODEL VG06049WHT6036C - MODEL 60X74
ALLEN KEY PACK
MISC
19.
