I & II Power Supply
Power Factor Corrected AC-DC Switcher
Overview
The Javelin is a ruggedized, switching power supply that combines the advantages of power factor correction
and power density with user-selectable output voltage and power. Accepting input voltages of 85 to 254 VAC
and 85 to 380 VDC, the Javelin can provide up to 1800 watts in a 4.9 H x 7.0 W x 10.75 L (9.5 L for Javelin
II) package. Its inherent flexibility comes from its use of Vicor 2
nd Generation DC-DC converters. Javelin I has
a 100 CFM fan installed, while Javelin II utilizes customer-provided forced-air cooling.
Standard Features
 Power Factor Correction: .99 at 115 VAC; .95 at 230 VAC.
 Universal Input: 85-254 VAC, 47-500 Hz, or 85-380 VDC.
 Power Output: 1800W at 230 VAC for selected outputs; 800W at 115 VAC (See Graph 1, Pg 13, for
breakdown of input voltage vs. output power).
 Full power to 55C; half power at 70C . (See Graph 2, Pg 14 for breakdown of output power vs. ambient
temperature.)
 Soft start for limiting inrush current.
 EMI Compliance: FCC Class A; EN 55022 Class A & B; MIL-STD-461E.
 Transient Protection: MIL-STD-704E.
 Environmental: MIL-STD-810E.
 MIL-STD-1399 (300A); 115VAC, 60Hz, single phase; 1KVA5KVA.
 Harmonic Distortion to EN61000-3-2.
 AC Power OK status signal.
 Fan cooled (Javelin I only, Javelin II requires 100 CFM to be provided by customer).
 Equipped with Auto-Sense.
 Output overcurrent, overvoltage and overtemperature protection.
 Ride-through (holdup) time: 20 ms at 1200W load.
 Size: 4.9 H x 7.0 W x 10.75 L (9.5 L for Javelin II).
 Heavy-duty “ruggedized” enclosure designed for a high shock and vibration environment.
 Extra cooling provided for higher output with increased altitude capability.
 “D” shell connectors for input and interface connections.
Technical Description
The Javelin consists of a DC or off-line single phase power-factor-corrected front end, with an EMI filter, cool-
ing fan (Javelin I), customer interface, associated housekeeping circuits, and a selection of Vicor’s DC-DC con-
verters.
Input DC or AC mains voltage is applied to a 3-pin power connector. The input current is passed through an
EMI filter designed to meet conducted noise limit specification EN55022, level A and B.
At start-up, inrush current is limited by a PTC thermistor. The PTC is shunted out shortly after initial power-up
by a DC bus voltage sense circuit driving a thyristor. After rectification, the input voltage is put through a
boost converter that keeps the AC input current sinusoidal and synchronized with the input AC voltage (in
compliance with EN61000-3-2). The boost converter delivers a regulated input to the hold-up capacitors and a
high voltage backplane. The backplane supplies power to the DC-DC converters that provide the desired low
voltage, regulated output.
