REPLACEMENT PARTS AND TECHNICAL SUPPORT
Contact UVP for a list of replacement parts for the BC-300 Benchtop Curing System. UVP offers technical
support for all of its products. If you have any questions about the product’s use, operation or repair, contact
our offices below.
NOTE: A Returned Goods Authorization (RGA) number must be obtained from UVP Customer Service
before returning a product to UVP.
UVP, Inc. Ultra-Violet Products Ltd.
2066 W. 11th Street Unit 1, Trinity Hall Farm Estate
Upland, CA 91786 Nuffield Road
Tel: (800) 452-6788 or Cambridge CB4 1TG UK
(909) 946-3197 Tel: +44(0) 1223-420022
Fax: (909) 946-3597 Fax: +44(0) 1223-420561
E-Mail: [email protected] E-Mail: [email protected]
TROUBLE SHOOTING AND PRODUCT DIAGRAMS
A troubleshooting check list for 208/220/420/440 volt 50/60 hertz conveyorized curing system models is
shown on page 7.
NOTE: Because of the high voltage used throughout the power supply, only qualified personnel
should work on it.
Wiring Diagrams, Lamp Installation Instruction Sheets, and Installation of Drop Off Plate are provided on the
following pages.
BC-300 Benchtop UV Curing System
6
C. Remount the metal air diffuser with 8-32x3/16” screws. Place the top bracket over the lamp end and
tighten both screws. Mount the wire lead from the lamp end to the ceramic standoff and replace the
8-32 nut. Repeat on the oppositve side of the lamp.
7. Place the irradiator back in place and tighten the (4) 10-32 knobs. Reconnect the high voltage cable by
matching index to index insuring proper connection and screw connector cable down completely.
CAUTION: When the fixture is opeating, ultraviolet rays are emitted which are harmful to eyes and skin.
Great care should be taken to insure personnel are not exposed to direct or reflected radiation. Suitable eye
and skin protection, such as UVP UV Blocking Spectacles and Goggles should be worn when the lamp is in
operation. Before cleaning or relamping, ALWAYS TURN POWER OFF.
