UVP ChemiDoc-It Imaging System - Manual (Page 5)

ChemiDoc-It Imaging System 5
Setup Instructions
Installing VisionWorksLS Software
1. Insert the VisionWorksLS flash drive into the computer.
2. Click on the Install button for VisionWorksLS.
3. Click OK, Next, agree to “I accept terms of licensing agreement”, then Next. Leave all options in
their default settings. Then click Next, Next, Install and finally Finish.
Registering the Software
Open the Software
1. Double click the VisionWorksLS
software icon on the desktop.
2. To activate the software,
registration is required. To
immediately activate the software
online, choose On-the-Fly
activation. If the computer is not
connected to the Internet, select
Offline activation and proceed to
the following page of this manual,
or call UVP to register the
software.
3. Click Next to continue.
4. The Already have an activation
ID option is useful when reloading
the software after receiving an
initial activation code.
5. Complete all required information
on the form.
6. Fill out the Serial Number field on
the registration page. The number
is located on the installation CD.
The number should be four sets of
six numbers.
7. Once the form is completed, click
on Get Activation No. and then
click Activate once the Activation
Number appears in the box.
