7. Remove the bolts that retain the gearbox to the frame and remove the gearbox by guiding it out of the
vehicle and moving it toward the passenger side. Once the box and shaft assembly is out, set it
aside, it will not be needed again.
8. Remove the stock round crossmember from the vehicle and install the rack and pinion assembly in its
place. Use the supplied bolts to put it in place and tighten to 65 ft.lbs.
9. When installing the bracket and rack it may be necessary to grind slightly on the frame mount where
the camber adjusters are for clearance. Some cars need this, others don’t.
Gearbox
May need
to grind
here May need to
grind here
