Electric motor & Fan Data
Fan
Motor
Full Load
nema
Thermal Approx. shipping
sound
Model
CFM
H.P.
Voltage
Phase
Amps
Hz
RPM
Frame
Overload
Weight (Lbs.)
dB(A) at 3 ft
AHP-400
2200
1.0
115/208-230
1
6.0
60
3450
120
97
1825/2200
208-230/460
3
3.6/3.2
50/60
2850/3450
56C
AHP-725
3600
1.5
115/208-230
1
8.5
60
3450
170
100
3025/3600
208-230/460
3
4.8/4.2
50/60
2850/3450
AHP-950
4700
1.5
115/208-230
1
8.6
145TC
330
92
208-230/460
3
4.6
AHP-1200
7000
5.0
230
1
23.0
184TC
No
450
94
3.0
208-230/460
3
8.8
182TC
AHP-1600
9700
5.0
208-230/460
13.4
60*
1740
184TC
515
96
AHP-2000
11000
19.6
600
98
AHP-2500
14000
7.5
230/460
3
213TC
625
98
AHP-3000
17500
24.8
645
102
AHP-3500
17500
10.0
215TC
750
102
All motors shown are TEFC. Other motor options available upon request. Published electrical ratings are approximate, and may vary because of motor brand. Actual ratings are
on motor nameplate.
Fan motors must not be cycled. Outdoor applications must be protected from direct weather. If ductwork or additional static resistance is added to the cooler airstream, an
auxiliary air mover may be required.
*3 phase motors available in 50Hz. Reduce performance by 10%.
Recommended Typical Installation
1. Support piping as needed. Flexible connectors must be properly installed
to validate warranty.
2. Coolers should not operate in ambient temperatures below 35°F (1°C).
Consult factory for recommendations.
3. The fan cannot be cycled.
4. AHP coolers operated outdoors must be protected from weather.
Consult factory for recommendations.
5. If ductwork or additional static resistance is added to the cooler airstream,
an auxiliary air mover may be required.
