Thermal Transfer Systems Air ACOC Series User Manual
Ac o c /ac o c h, Compressed air cooling | air acoc/acoch series, How to order

AC
O
C
/AC
O
C
H
262.554.8330
www.thermaltransfer.com
142
COmpREssED AIR COOLING | Air ACOC/ACOCH series
A
IR C
O
O
L
E
D
AC
O
C
(H
)
How to Order
Model
series
ACOC
Model size
selected
400
725
950
1200
1600
2000
2500
3000
3500
–
–
ACOC
specify Motor
Required
0
- No Motor
(includes Fan Blade & Fan Guard)
2
- Single Phase
3
- Three Phase
6
- 575 Volt
BRAzED ALUMinUM COnsTRUCTiOn
Features
n
Combination Welded Cores – Air & Oil Core
n
Brazed Aluminum Core/Bar and Plate
n
Excellent for Field Conversions
n
Vertical Air Flow
n
Compact Design
n
Light Weight
n
Compact, high performance all aluminum
core assembly
n
Designed specifically for rotary screw
compressors
n
Ideal for converting water cooled units to
air cooled
n
Eliminates high water and sewer costs
n
Eliminates corrosion problems associated
with water cooled units
n
Vertical air flow works well for heat recovery
n
State-of-the-art heat transfer technology
n
Detachable Legs (ACOC) Shipped Unattached
Fixed Mounting Feet on ACOCH
Materials
Legs Steel with Baked Enamel Finish
shroud Steel
Core Brazed Aluminum Bar and Plate
Fan Aluminum Hub, Plastic Blades
Motor TEFC
Ratings
Maximum Operating Pressure 250 psi
Maximum Operating Temperature 350°F
Model
series
ACOCH
Model size
selected
400
725
950
1200
1600
2000
–
–
ACOCH
specify Motor
Required
0
- No Motor
(includes Fan Blade & Fan Guard)
2
- Single Phase
3
- Three Phase
6
- 575 Volt
OiL
COOLER
AiR
AFTERCOOLER
OiL
COOLER
AiR
AFTERCOOLER
