800.851.4965 TerraWave.com/APsystems [email protected]
 Clear/ Transparent door for enclosure
 CAT60 Key Lock for enclosure
 Wall mount kit —
SKU 363287
 Pole mount kit —
SKU 303580
 MIMO Patch Antenna w/ Articulating Mount
— SKU 349502
 High Gain, Point-to-Point Antenna
— SKU 572251
PoE Power System Enclosure Specifications
Dimensions (W x L x H) 12” x 10” x 6”
Enclosure Material Polycarbonate
Color Grey
NEMA Rating 3
Environmental Temp Range -22 to 128 F (-30 to 53.33 C)
Heating
Thermostat Operation 15 Watt (heat)
On: 37.94 F , Off: 53 F
Cooling
Thermostat Operation 49 CFM DC fan
On: 104 F , Off: 89 F
Lightning Arrestors
Range: DC 0-6 GHz
Impulse: 20 KA (Wave 8/20 µ)
PoE Surge Suppression
Discharge Current: 10 KA
Peak Pulse: 100 A
(10/1000 µ)
Input Power 15.5W PoE
RF Connections RPTNC
Weight 14 lbs
Warranty Manufacturer's warranty on components. 1 year on workmanship.
Optional Accessories
System w/ Integrated Omni Antenna System w/ External Patch Antenna
