Features
◊
Integrated cooling system
◊
Integrated with one 2 pack (Aruba 92), 3 pack (Aruba
134) or 4 pack (Aruba 104) antenna including all internal
patch cables
◊
RF surge arrestors are designed into the system with
ground bars and ground wires protecting the AP
◊
Plug-and-play system fully integrated from the factory
Benefits
◊
System engineered to allow safe operability in outdoor
environments
◊
Single antenna design for MIMO applications eliminates
multiple antenna installation costs and time
◊
Protects your Aruba 92/134/104 access point from the
outdoor environment
◊
Minimal installation time
*External Patch Antenna sold separately.
System Highlights
◊
Uninterruptible Power Supply (UPS) provides reliable power
to your network in the case of a power outage
◊
True plug-and-play system with heating capability for
outdoor deployments
◊
Robust aluminum back plate that allows for seamless
integration with Aruba’s 92, 134 and 104 access points
◊
Ideal for mission critical applications
◊
802.3af compliant
◊
Requires Cat5 cable only. PoE Injector allows system to run
smoothly
UPS Enclosure System
For Aruba 92,134 & 104 Access Points
Aruba Access Point UPS Enclosure Systems
System w/ External
Patch Antenna*
System w/
Integrated Omni
Antenna
92 VA09-12-055-AP26 VA09-12-055-AP33
134 VA09-12-055-AP50 VA09-12-055-AP57
104 VA09-12-055-AP38 VA09-12-055-AP45
System Includes
Grey Polycarbonate Enclosure w/ Latch Locks 9 9
Predrilled Aluminum Back Plate—AP specific 9 9
RF Jumpers 9 9
RF Surge Protectors 9 9
PoE Power Surge Arrestor w/ Ethernet Cable 9 9
Ground System w/ Ground Stud, Bar & Wires 9 9
Omni MIMO Antenna 9
*Wires and cable not shown for clarity.
**AP sold separately.
