— 9 —
Table 2A — Electrical Data (Units Without Electrical Convenience Outlet) (cont)
NOTE: Legend and Notes for Electrical Data are on page 12.
UNIT
548F NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC
HEAT*
POWER SUPPLY
DISCONNECT
SIZE†
Min Max RLA LRA
Nominal
kW**
FLA MCA MOCP FLA LRA
048
(4 Tons)
(cont)
460-3-60
STD 414 508 7.1 52.5 0.8 1.8
— — 11.5 15†† 11 59
6.0 7.2 20.5 25†† 19 66
11.5 13.8 28.7 30†† 27 73
14.0 16.8 32.5 35†† 30 76
23.0 27.7 46.1 50†† 43 86
ALT 414 508 7.1 52.5 0.8 2.1
— — 11.8 15†† 12 61
6.0 7.2 20.8 25†† 20 68
11.5 13.8 29.0 30†† 27 74
14.0 16.8 32.8 35†† 31 77
23.0 27.7 46.4 50†† 43 88
HIGH-STATIC 414 508 7.1 52.5 0.8 2.6
— — 13.9 15†† 14 72
6.0 7.2 22.9 25†† 22 80
11.5 13.8 31.2 35†† 29 86
14.0 16.8 34.9 35†† 33 89
23.0 27.7 48.5 50†† 45 100
575-3-60
STD 518 632 6.0 44.0 0.8 1.8 — — 9.6 15†† 9 49
ALT 518 632 6.0 44.0 0.8 2.1 — — 9.8 15†† 10 50
HIGH-STATIC 518 632 6.0 44.0 0.8 2.6 — — 11.1 15†† 11 55
060
(5 Tons)
208/230-1-60
STD 187 254 26.7 170.0 1.5 5.9
— — 40.8/ 40.8 45/ 45†† 39/ 39 184/184
4.9/ 6.5 23.6/27.0 70.3/ 74.7 80/ 80 66/ 70 208/211
6.5/ 8.7 31.3/36.3 79.9/ 86.2 80/ 90 75/ 81 215/220||
9.8/13.0 47.1/54.2 99.7/108.5 100/110 93/102 231/238||
13.1/17.4 63.0/72.5 119.5/131.4 125/150 112/123 247/257||
15.8/21.0 76.0/87.5 135.8/150.2 150/175 127/140 260/272||
ALT 187 254 26.7 170.0 1.5 8.8
— — 48.5/ 48.5 50/ 50†† 48/ 48 222/222
4.9/ 6.5 23.6/27.1 78.0/ 82.4 80/ 90 75/ 79 246/249
6.5/ 8.7 31.3/36.3 87.6/ 93.9 90/100 84/ 90 253/258||
9.8/13.0 47.1/54.2 107.4/116.2 110/125 102/110 269/276||
13.1/17.4 63.0/72.5 127.2/139.1 150/150 121/131 285/294||
15.8/21.0 76.0/87.5 143.5/157.9 150/175 135/149 298/309||
208/230-3-60
STD 187 254 15.4 124.0 1.5 5.9
— — 26.7/ 26.7 30/ 30†† 26/ 26 138/138
4.9/ 6.5 13.6/15.6 43.7/ 46.2 45/ 50†† 42/ 44 152/154
7.9/10.5 21.9/25.3 54.0/ 58.3 60/ 60†† 51/ 55 160/163
12.0/16.0 33.3/38.5 68.3/ 74.8 70/ 80 65/ 70 171/177
15.8/21.0 43.9/50.5 81.5/ 89.8 90/ 90 77/ 84 182/189||
19.9/26.5 55.2/63.8 95.7/106.4 100/110 90/100 193/202||
ALT 187 254 15.4 124.0 1.5 5.8
— — 26.6/ 26.6 30/ 30†† 26/ 26 169/169
4.9/ 6.5 13.6/15.6 43.6/ 46.1 45/ 50†† 42/ 44 182/184
7.9/10.5 21.9/25.3 53.9/ 58.2 60/ 60 51/ 55 191/194
12.0/16.0 33.3/38.5 68.2/ 74.7 70/ 80 64/ 70 202/207
15.8/21.0 43.9/50.5 81.4/ 89.7 90/ 90 77/ 84 213/219||
19.9/26.5 55.2/63.8 95.6/106.3 100/110 90/ 99 224/233||
HIGH-STATIC 187 254 15.4 124.0 1.5 7.5
— — 28.3/ 28.3 30/ 30†† 28/ 28 188/188
4.9/ 6.5 13.6/15.6 45.3/ 47.8 50/ 50†† 44/ 46 201/203
7.9/10.5 21.9/25.3 55.6/ 59.9 60/ 60†† 53/ 57 210/213
12.0/16.0 33.3/38.5 69.9/ 76.4 70/ 80 66/ 72 221/226
15.8/21.0 43.9/50.5 83.1/ 91.4 90/100 79/ 86 232/238||
19.9/26.5 55.2/63.8 97.3/108.0 100/110 92/101 243/252||
460-3-60
STD 414 508 7.7 59.6 0.8 3.2
— — 13.6 15†† 13 67
6.0 7.2 22.6 25†† 22 75
11.5 13.8 30.9 35†† 29 81
14.0 16.8 34.6 35†† 33 84
23.0 27.7 48.3 50†† 45 95
25.5 30.7 52.0 60†† 49 98
ALT 414 508 7.7 59.6 0.8 2.6
— — 13.0 15†† 13 82
6.0 7.2 22.0 25†† 21 89
11.5 13.8 30.3 35†† 29 96
14.0 16.8 34.0 35†† 32 99
23.0 27.7 47.7 50†† 45 110
25.5 30.7 51.4 60†† 48 113
HIGH-STATIC 414 508 7.7 59.6 0.8 3.4
— — 13.8 15†† 14 92
6.0 7.2 22.8 25†† 22 99
11.5 13.8 31.1 35†† 30 105
14.0 16.8 34.8 35†† 33 108
23.0 27.7 48.5 50†† 46 119
25.5 30.7 52.2 60†† 49 122
575-3-60
STD 518 632 6.2 49.4 0.8 3.2 — — 11.0 15†† 11 56
ALT 518 632 6.2 49.4 0.8 2.6 — — 10.5 15†† 10 67
HIGH-STATIC 518 632 6.2 49.4 0.8 3.4 — — 11.1 15†† 11 75
072
(6 Tons)
208/230-3-60
STD 187 254 22.7 146.0 1.4 5.8
— — 35.6/ 35.6 40/ 40†† 34/ 34 190/190
4.9/ 6.5 13.6/15.6 52.6/ 55.1 60/ 60†† 50/ 52 204/206
7.9/10.5 21.9/25.3 63.0/ 67.2 70/ 70 60/ 63 212/215
12.0/16.0 33.3/38.5 77.2/ 83.7 80/ 90 73/ 79 223/229
15.8/21.0 43.9/50.5 90.5/ 98.7 100/100 85/ 92 234/241||
19.9/26.5 55.2/63.8 104.6/115.3 110/125 98/108 245/254||
HIGH-STATIC 187 254 22.7 146.0 1.4 7.5
— — 37.3/ 37.3 40/ 40†† 36/ 36 209/209
4.9/ 6.5 13.6/15.6 54.3/ 56.8 60/ 60†† 52/ 54 223/225
7.9/10.5 21.9/25.3 64.7/ 68.9 70/ 70 62/ 65 231/234
12.0/16.0 33.3/38.5 78.9/ 85.4 80/ 90 75/ 81 242/248||
15.8/21.0 43.9/50.5 92.2/100.4 100/110 87/ 94 253/260||
19.9/26.5 55.2/63.8 106.3/117.0 110/125 100/110 264/273||
460-3-60
STD 414 508 11.4 73.0 0.7 2.6
— — 17.6 20†† 17 95
6.0 7.2 26.6 30†† 25 102
11.5 13.8 34.8 35†† 33 109
14.0 16.8 38.6 40†† 36 112
23.0 27.7 52.2 60†† 49 123
25.5 30.7 55.9 60†† 52 126
HIGH-STATIC 414 508 11.4 73.0 0.7 3.4
— — 18.4 20†† 18 105
6.0 7.2 27.4 30†† 26 112
11.5 13.8 35.6 40†† 34 118
14.0 16.8 39.4 40†† 37 121
23.0 27.7 53.0 60†† 50 132
25.5 30.7 56.7 60†† 53 135
575-3-60
STD 518 632 9.1 58.4 0.7 2.6 — — 14.0 15†† 14 76
HIGH-STATIC 518 632 9.1 58.4 0.7 3.4 — — 14.7 15†† 14 84
