— 22 —
Table 8 — Fan Performance, 548F036 Standard Motor — Vertical Discharge Units
LEGEND
NOTES:
1. Values include losses for filters, unit casing, and wet coils. See
Table 7 for accessory/FIOP static pressure information.
2. Extensive motor and electrical testing on these units ensures that
the full range of the motor can be utilized with confidence. Using
your fan motors up to the wattage ratings shown will not result in
nuisance tripping or premature motor failure. Unit warranty will not
be affected. For additional information on motor performance, refer
to Indoor-Fan Motor Performance, Table 6.
3. Use of a field-supplied motor may affect wire sizing. Contact your
Bryant representative for details.
Table 9 — Fan Performance, 548F036 Alternate Motor — Vertical Discharge Units
LEGEND
*Motor drive range: 760 to 1000 rpm. All other rpms require field-
supplied drive.
NOTES:
1. Boldface indicates field-supplied drive is required.
2. indicates field-supplied motor and drive are required.
3. Maximum usable watts input is 1000 and maximum continuous
bhp is 1.00. Extensive motor and electrical testing on these units
ensures that the full range of the motor can be utilized with confi-
dence. Using your fan motors up to the wattage ratings shown will
not result in nuisance tripping or premature motor failure. Unit war-
ranty will not be affected. For additional information on motor per-
formance, refer to Indoor-Fan Motor Performance, Table 6.
4. Values include losses for filters, unit casing, and wet coils. See
Table 7 for accessory/FIOP static pressure information.
5. Use of a field-supplied motor may affect wire sizing. Contact your
Bryant representative for details.
6. Interpolation is permissible. Do not extrapolate.
548F036 (3 TONS) — STANDARD MOTOR (DIRECT DRIVE)
Airflow
(Cfm)
Low Speed High Speed
208 v 230, 460, 575 v 208 v 230, 460, 575 v
ESP Bhp Watts ESP Bhp Watts ESP Bhp Watts ESP Bhp Watts
900 0.67 0.21 253 0.68 0.23 277 0.69 0.26 307 0.69 0.31 363
1000 0.60 0.23 270 0.61 0.25 292 0.61 0.27 321 0.63 0.32 374
1100 0.55 0.24 287 0.56 0.26 307 0.57 0.28 335 0.58 0.33 385
1200 0.51 0.26 304 0.51 0.27 323 0.52 0.29 349 0.53 0.34 397
1300 0.45 0.27 321 0.46 0.29 338 0.46 0.31 364 0.47 0.34 408
1400 0.38 0.29 338 0.41 0.30 354 0.43 0.32 378 — — —
1500 0.34 0.30 355 0.36 0.31 369 0.38 0.33 392 — — —
Bhp — Brake Horsepower Input to Fan
ESP — External Static Pressure (in. wg)
FIOP — Factory-Installed Option
Watts — Input Watts to Motor
548F036 (3 TONS) — ALTERNATE MOTOR (BELT DRIVE)*
Airflow
(Cfm)
External Static Pressure (in. wg)
0.1 0.2 0.3 0.4 0.5 0.6
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
900 581 0.12 119 673 0.18 179 736 0.22 219 805 0.25 249 865 0.29 288 911 0.34 338
1000 644 0.19 189 709 0.22 219 782 0.28 279 835 0.30 298 900 0.35 348 937 0.38 378
1100 687 0.22 219 746 0.26 259 806 0.30 298 867 0.35 348 929 0.40 398 964 0.40 398
1200 733 0.26 259 785 0.32 318 843 0.35 348 903 0.41 408 960 0.47 467 994 0.50 497
1300 754 0.29 288 826 0.38 378 891 0.43 428 942 0.48 477 991 0.53 527 1047 0.60 597
1400 810 0.35 348 868 0.45 448 937 0.51 507 984 0.57 567 1032 0.62 617 1067 0.67 666
1500 841 0.42 418 911 0.53 527 985 0.61 607 1029 0.66 656 1073 0.72 716 1109 0.77 766
548F036 (3 TONS) — ALTERNATE MOTOR (BELT DRIVE)* (cont)
Airflow
(Cfm)
External Static Pressure (in. wg)
0.7 0.8 0.9 1.0 1.1 1.2
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
900 957 0.39 388 988 0.43 428 1039 0.45 448 1061 0.47 487 1083 0.53 527 1105 0.57 567
1000 992 0.44 438 1039 0.49 487 1061 0.51 507 1086 0.55 547 1111 0.59 587 1136 0.63 627
1100 1013 0.49 487 1068 0.55 547 1090 0.58 577 1109 0.61 607 1127 0.64 637 1145 0.67 666
1200 1045 0.56 557 1090 0.64 637 1109 0.64 647 1156 0.68 676 1203 0.71 706 1250 0.74 736
1300 1075 0.64 637 1122 0.70 696 1152 0.72 716 1190 0.76 756 1228 0.80 796 1266 0.84 836
1400 1110 0.73 726 1160 0.84 766 1181 0.81 806 1237 0.85 845 1293 0.89 885 1349 0.93 925
1500 1150 0.82 816 1190 1.00 855 1225 0.90 895 1271 0.95 945 1317 1.00 995 1363 1.05 1044
Bhp — Brake Horsepower Input to Fan
FIOP — Factory-Installed Option
Watts — Input Watts to Motor
