— 11 —
Table 2B — Electrical Data (Units With Electrical Convenience Outlet) (cont)
NOTE: Legend and Notes for Electrical Data are on page 12.
UNIT
548F NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(each) OFM
FLA
IFM
FLA
ELECTRIC
HEAT*
POWER SUPPLY
DISCONNECT
SIZE†
Min Max RLA LRA
Nominal
kW**
FLA MCA MOCP FLA LRA
048
(4 Tons)
(cont)
460-3-60
STD 414 508 7.1 52.5 0.8 1.8
— — 13.7 15†† 14 61
6.0 7.2 22.7 25†† 22 68
11.5 13.8 30.9 35†† 30 75
14.0 16.8 34.7 35†† 33 78
23.0 27.7 48.3 50†† 46 89
ALT 414 508 7.1 52.5 0.8 2.1
— — 14.0 15†† 14 63
6.0 7.2 23.0 25†† 22 70
11.5 13.8 31.2 35†† 30 77
14.0 16.8 35.0 40†† 33 80
23.0 27.7 48.6 50†† 46 90
HIGH-STATIC 414 508 7.1 52.5 0.8 2.6
— — 16.1 20†† 16 75
6.0 7.2 25.1 30†† 24 82
11.5 13.8 33.3 35†† 32 88
14.0 16.8 37.1 40†† 35 91
23.0 27.7 50.7 60†† 48 102
575-3-60
STD 518 632 6.0 44.0 0.8 1.8 — — 11.3 15†† 11 51
ALT 518 832 6.0 44.0 0.8 2.1 — — 11.6 15†† 12 52
HIGH-STATIC 518 832 6.0 44.0 0.8 2.6 — — 12.8 15†† 13 57
060
(5 Tons)
208/230-1-60
STD 187 254 26.7 170.0 1.5 5.9
— — 45.6/ 45.6 50/ 50†† 45/ 45 189/189
4.9/ 6.5 23.6/27.1 75.1/ 79.5 80/ 80 72/ 76 213/216
6.5/ 8.7 31.3/36.3 84.7/ 91.0 90/100 81/ 86 220/225||
9.8/13.0 47.1/54.2 104.3/113.3 110/125 99/107 236/243||
13.1/17.4 63.0/72.5 124.3/136.2 150/150 117/128 252/261||
15.8/21.0 76.0/87.5 140.6/155.0 150/175 132/145 265/276||
ALT 187 254 26.7 170.0 1.5 8.8
— — 48.5/ 48.5 50/ 50†† 48/ 48 222/222
4.9/ 6.5 23.6/27.1 78.0/ 82.4 80/ 90 75/ 79 246/249
6.5/ 8.7 31.3/36.3 87.6/ 93.9 90/100 84/ 90 253/258||
9.8/13.0 47.1/54.2 107.4/116.2 110/125 102/110 269/276||
13.1/17.4 63.0/72.5 127.2/139.1 150/150 121/131 285/294||
15.8/21.0 76.0/87.5 143.5/157.9 150/175 135/149 298/309||
208/230-3-60
STD 187 254 15.4 124.0 1.5 5.9
— — 31.5/ 31.5 35/ 35†† 32/ 32 143/143
4.9/ 6.5 13.6/15.6 48.5/ 51.0 50/ 60†† 47/ 50 157/159
7.9/10.5 21.9/25.3 58.8/ 63.1 60/ 70 57/ 61 165/168
12.0/16.0 33.3/38.5 73.1/ 79.6 80/ 90 70/ 76 176/181
15.8/21.0 43.9/50.5 86.3/ 94.6 90/100 82/ 90 187/193||
19.9/26.5 55.2/63.8 100.5/111.2 110/125 95/105 198/207||
ALT 187 254 15.4 124.0 1.5 5.8
— — 31.4/ 31.4 35/ 35†† 32/ 32 174/174
4.9/ 6.5 13.6/15.6 48.4/ 50.9 50/ 60†† 47/ 50 187/189
7.9/10.5 21.9/25.3 58.7/ 63.0 60/ 70 57/ 61 195/199
12.0/16.0 33.3/38.5 73.0/ 79.5 80/ 90 70/ 76 207/212
15.8/21.0 43.9/50.5 86.2/ 94.5 90/100 82/ 90 217/224||
19.9/26.5 55.2/63.8 100.4/111.1 110/125 95/105 229/237||
HIGH-STATIC 187 254 15.4 124.0 1.5 7.5
— — 33.1/ 33.1 35/ 35†† 34/ 34 193/193
4.9/ 6.5 13.6/15.6 50.1/ 52.6 60/ 60†† 49/ 52 206/208
7.9/10.5 21.9/25.3 60.4/ 64.7 70/ 70 59/ 63 214/218
12.0/16.0 33.3/38.5 74.7/ 81.2 80/ 90 72/ 78 226/231
15.8/21.0 43.9/50.5 87.9/ 96.2 90/100 84/ 92 236/243||
19.9/26.5 55.2/63.8 102.1/112.8 110/125 97/107 248/256||
460-3-60
STD 414 508 7.7 59.6 0.8 3.2
— — 15.8 20†† 16 70
6.0 7.2 24.8 30†† 24 77
11.5 13.8 33.1 35†† 32 83
14.0 16.8 36.8 40†† 35 86
23.0 27.7 50.4 60†† 48 97
25.5 30.7 54.2 60†† 51 100
ALT 414 508 7.7 59.6 0.8 2.6
— — 15.2 20†† 15 84
6.0 7.2 24.2 30†† 24 91
11.5 13.8 32.5 35†† 31 98
14.0 16.8 36.2 40†† 35 101
23.0 27.7 49.8 60†† 47 112
25.5 30.7 53.6 60†† 51 115
HIGH-STATIC 414 508 7.7 59.6 0.8 3.4
— — 16.0 20†† 16 94
6.0 7.2 25.0 25†† 24 101
11.5 13.8 33.3 35†† 32 107
14.0 16.8 34.8 35†† 33 108
23.0 27.7 50.6 60†† 48 121
25.5 30.7 54.4 60†† 51 124
575-3-60
STD 518 632 6.2 49.4 0.8 3.2 — — 12.7 15†† 13 57
ALT 518 632 6.2 49.4 0.8 2.6 — — 12.2 15†† 12 69
HIGH-STATIC 518 632 6.2 49.4 0.8 3.4 — — 12.9 15†† 13 77
072
(6 Tons)
208/230-3-60
STD 187 254 22.7 146.0 1.4 5.8
— — 40.4/ 40.4 45/ 45†† 40/ 40 195/195
4.9/ 6.5 13.6/15.6 57.4/ 59.9 60/ 60†† 56/ 58 208/211
7.9/10.5 21.9/25.3 67.8/ 72.0 70/ 80 65/ 69 217/220
12.0/16.0 33.3/38.5 82.0/ 88.5 90/ 90 78/ 84 228/233||
15.8/21.0 43.9/50.5 95.3/103.5 100/110 90/ 98 239/245||
19.9/26.5 55.2/63.8 109.4/120.1 110/125 103/113 250/259||
HIGH-STATIC 187 254 22.7 146.0 1.4 7.5
— — 42.1/ 42.1 45/ 45†† 42/ 42 214/214
4.9/ 6.5 13.6/15.6 59.1/ 61.6 60/ 70 58/ 60 227/229
7.9/10.5 21.9/25.3 69.5/ 73.7 70/ 80 67/ 71 236/239
12.0/16.0 33.3/38.5 83.7/ 90.2 90/100 80/ 86 247/252||
15.8/21.0 43.9/50.5 97.0/105.2 100/110 92/100 258/264||
19.9/26.5 55.2/63.8 111.1/121.8 125/125 105/115 269/278||
460-3-60
STD 414 508 11.4 73.0 0.7 2.6
— — 19.7 20†† 19 97
6.0 7.2 28.7 30†† 28 104
11.5 13.8 37.0 40†† 35 111
14.0 16.8 40.7 45†† 39 114
23.0 27.7 54.4 60†† 51 125
25.5 30.7 58.1 60†† 55 128
HIGH-STATIC 414 508 11.4 73.0 0.7 3.4
— — 20.5 25†† 20 107
6.0 7.2 29.5 30†† 29 114
11.5 13.8 37.8 40†† 36 121
14.0 16.8 41.5 45†† 40 124
23.0 27.7 55.2 60†† 52 134
25.5 30.7 58.9 60†† 56 137
575-3-60
STD 518 632 9.1 58.4 0.7 2.6 — — 15.8 20†† 16 78
HIGH-STATIC 518 632 9.1 58.4 0.7 3.4 — — 16.4 20†† 16 85
