Parts List
ITEM # DESCRIPTION PART #
not shown Log Set (optional) GC60-930
not shown Glass Tinted (optional) GC60-946
not shown 120 CERAMIC EXHAUST TEMP SENSOR GF55-009
not shown WINDOW CHANNEL TAPE 72" GF55-018
not shown 5/8" DOOR GASKET 7' GF55-019
not shown PED & ASHPAN GASKET 10' GF55-020
not shown PELLET MECHANICAL & ELEC FASTERNER BAG GF55-021
not shown BURN POT SCRAPER TOOL GF55-023
not shown DOMESTIC POWER CORD GF55-025
not shown HEYCO STRAIN RELIEF GF55-026
not shown PELLET SERVICE TOOL KIT GF55-031
not shown MAGNAHELIC GAUGE (TESTING UNIT) GF55-035
not shown PELLET STOVE CLEANING BRUSH GF55-048
not shown PELLET STOVE THERMOSTAT GC60-001
not shown DOOR & ASH DOOR GASKET 9/16 FIRM (10') W/JOINING TAPE(2) GC60-019
not shown GLASS RETAINER GC60-025
not shown LATCH BOLT & ROLLERS C/W NUT GC60-031
not shown 2 AMP SMALL FUSE GC60-032
not shown 4 AMP SMALL FUSE IGNITOR GC60-033
not shown ADJ AUGER FEED COVER KIT (N/C) PRE NOV 2010 GC60-034
not shown COMBUSTION BLOWER MOUNTING GASKET C-10859 GC60-035
not shown MAGNET 0.5" X 0.25" (NEO 45) GC60-036
not shown CONVECTION FAN CAPACITOR GC60-039
not shown CERAMIC REFRACTORY BRICK LINER KIT GC60-044
not shown HEAT EXCHANGER SCRAPER ROD GC60-047
not shown GC60 OWNERS MANUAL GC60-053
not shown GC60 TECHNICAL MANUAL GC60-054
1 AUGER WITH PADDLES GC60-002
2 VACUUM SWITCH LOW PRESURE GC60-003
3 AUGER STOPS (CLEAR RUBBER) GC60-004
4 AUGER PLATE AND BUSHING (ASSEMBLY) GC60-005
5 BURN POT GC60-006
6 STAINLESS STEEL CAST AGITATOR W/ COUPLER GC60-007
7 AGITATOR DRIVE SHAFT W/SPROCKET GC60-008
8 MOTOR DRIVE SPROCKET GC60-009
9 1/4" SPRING PIN GC60-010
10 AIR PUMP GC60-011
11 AGITATOR BUSHING LEFT SIDE GC60-012
