figure 10: Corner installation.

Installation

m

obile

h

ome

i

nStallation

:

(76mm)

3"

(76mm)

3"

Wall thimble

manufactured by pellet

vent manufacturer

3"Fresh Air Intake

Optional Hearth Pad

Flooring

Steel Frame

Ground Wire Directly to Metal Chassis

1/4"Lag Bolts

Securely Fastened

● Secure the heater to the floor

using the four (4) holes in the

pedestal.

● Ensure the unit is electrically

grounded to the chassis of your

home (permanently).

● Do not install in a room people

sleep in.

● Outside fresh air is mandatory.

Secure outside air connections

directly to fresh air intake pipe

and secure with three (3) screws

evenly spaced.

● All specified components must

be used. Do not use any

components other than what’s

specified.

CAUTION: THE STRUCTURAL INTEGRITY OF THE MANUFACTURED HOME FLOOR, WALL

AND CEILING/ROOF MUST BE MAINTAINED.

c

orner

t

hrough

W

all

i

nStallation

:

figure 9: Mobile home installation.

Hampton GC60 Cast Pellet Stove Technical Manual

12
