46
Regency B36XTCE Gas Fireplace
INSTALLATION
C
3rd Grate Post
Notch in log C
Left Peg - Log E
8) Place the lava rocks on the front of the burner tray in the places
shown in the photo.
Separate platinum embers and place on the front of the burner tray
in and around the lava rocks. Avoid stacking platinum embers.
Platinum embers may be placed over burner ports.
9) Position Log C with the fl at side toward Log E.
Fit Log C onto left peg on Log E - the notch on the bottom of Log C
rests against the 3rd (from the left) grate post.
10) Test fi re to ensure proper light off (make sure fl ame fl ows
smoothly from one end of the burner to the other). If there is
any fl ame hesitation, check that area for any blockage of
the burner ports.
Lava Rocks
Platinum Embers
C
A
E
B
D
