Stack-On GSXW-836 40033-0708 - Manual (Page 2)

IMPORTANT
Keep keys and combination number in a secure place, away from children. Keep this record of your key number and combination
in a secure place separate from your safe. To order a replacement key set, follow the instructions on the attached form.
BATTERY REPLACEMENT
NOTE: When changing the battery, always hold the battery connecting cap while disconnecting or attaching the battery. Do not pull on the
wires. Doing this could cause the power supply to become disconnected from the lock.
This safe uses one 9V alkaline battery. Under normal use, batteries will last about 1 year.
When the battery is low and you press a button on the keypad, a red light will come on warning you that the battery is low.
To test the batteries, enter your security code. If the batteries are low the red light will come on momentarily.
To replace the battery, open the cover plate located on the bottom of the lock face with a small flat head screwdriver. Replace the old battery
and snap the cover plate back in place.
STACK-ON PRODUCTS CO., P.O. BOX 489, WAUCONDA, IL 60084
ELECTRONIC LOCK
You must first install the battery which is located in the front protective styrofoam (See BATTERY REPLACEMANT
below)
To open an electronic lock the first time, press the following numbers/symbols on the electronic keypad in this order: 1, 5, 9, # . (These
numbers are preset. You should change the entry code as soon as possible after opening the safe to insure proper security). After you have
entered the factory code, you will need to turn the handle clockwise to open the door. You will have 5 seconds to turn the handle before the
locking mechanism is reactivated.
ENTERING YOUR SECURITY CODE
To enter your own security code you will need to follow the steps listed below:
1. After opening the electronic safe (with the preset factory code of 1, 5, 9, #) locate the small red red button on the inside of the door near
the hinge.
2. Press the red button and then release it, you will hear a beep. The yellow light on the faceplate will be activated and will stay on for a
period of time that should allow you to enter your code. You can only enter your code while the yellow light is on.
With the door open and the yellow light on, enter your own personal security code, which can be 3 - 8 digits long, and confirm your new code
by pressing the " " symbol on the electronic touch pad. Before you close the door, try the new security code to make sure the lock
releases the handle so you can turn it and retract the live action bolts. DO NOT SHUT THE DOOR UNTIL YOU HAVE CONFIRMED THAT
YOUR NEW SECURITY CODE HAS BEEN ENTERED CORRECTLY.
If the code fails, go through steps 1 and 2 again. If the code works successfully record your combination number on the front of this form or
somewhere in your records, then you should lock the safe.
When you open the safe in the future enter the security code you have set followed by the "
#
" symbol.
If the incorrect security code is entered 3 times you will have an automatic lockout for 20 seconds before you can try your code again.
If the incorrect security code is entered 3 additional times there will be a 5-minute lockout before the code can be tried again.
TURNING THE KEYPAD SOUND OFF/ON
You can turn off the "Beep" sound of the keypad by entering the code 633.
To turn the "Beep" sound on, enter the code 66.
TROUBLE KEY
A "Trouble Key" has been provided in case you have forgotten or lost your
security code. To open the safe using the trouble key follow the steps below:
1. Slowly peel off the adhesive-backed touch pad starting from the right side.
Peel off only enough to expose the key hole. (Figure 5) Be careful not to
permanently bend or crease the touch pad.
2. Insert the key all the way through the lock face and into the door. Turn the
key clockwise 1/4 turn (until stopped) in order to unlock the safe. Rotate the
handle and open the door.
3. Before entering your new code, remove key and replace the adhesive-
backed touch pad. Keep the door open until you have entered a new security
code.
4. Enter your new security code following the instructions above.
WARNING
Keep your safe closed and locked at all times when not in use. Children could accidentally be locked inside the safe.
NOTE: Stack-On is not responsible for any cost incurred if the safe is replaced due to a flood.
5
KEY HOLE
40033-0708
2 12
