INSTALLATION
Included in delivery
Within the package of the snakebyte HDMI Selector you should find the following items:
1x HDMI Selector
1x HDMI cable (length 2 m)
1x IR remote control (incl. coin cell)
1x power supply unit
1x this manual
If any part is missing or obviously broken please contact your dealer immediately. If there are more
than the five mentioned items included – congratulations!
Setting up the device
Control panel
Front:
1. Channel select indicator: Four LEDs to indicate the selected channel
2. ON/STANDBY indicator: Indicates the device’s status (green: active, red: Standby)
3. ON/OFF Button & IR-Sensor: Make sure the IR sensor is not blocked or covered and within
clear sight when the remote control is used.
Top:
1. Channel +/-: Channel select without remote control. Pressing the „+“ button beyond channel
4 cycles back to channel 1 (and vice versa).
2. Equalizer: Signal loss compensation when used with cables exceeding 10 m length. Press „+“
to compensate bad quality signals. The respective channel LED will blink during this process.
