ASSEMBLY..... CONTINUED
Assemble the reflector pieces to the centre piece
using the 12 1/4” washers and secure with M8-125
butterfly wing nuts.
5 piece section
reflector
(32”dia)
one piece
option
(32”dia)
5 piece Sectional Reflector:
1/4”
Connect hose to valve by turning tight.
Secure entire top burner assembly to center post
with screws that are already affixed to the burner
assembly.
