Assembly..... continued – Schwank 4N/L62-J Pole Mounted User Manual
Page 10
GP-M45J-CX-03D
4N/L51-J,4N/L62-J Manual
RD: Aug 2006
RL: 3D
KH
ASSEMBLY..... CONTINUED
Page 6
Insert the gas hose provided, into the top of the pole
feeding it down inside right to the bottom.
Push the gas hose all the way down until it reaches
the bottom, pulling it out through the side opening.
Fit the 1” x 7” ribbed gas hose protection sleeve
over the end of the gas hose connection and slide it
all the way over the fitting onto the hose.
Place hose through the opening on bottom base.
Pull hose through upward inside center pole.
