Schwank STSV - Manual (Page 52)

52
STV-JZ I&O Manual
IM090512
RD: MAY 2009
RL: 08A- BA
See Exploded View previous page
# PART DESCRIPTION PART # PART DESCRIPTION PRIMARY SUPPLEMENT
14 BURNER HOUSING JS-0582-XX Burner Housing - Orange
15 BUSHING JF-1812-BL Snap-In Bushing 3/4"
16 IGNITION CABLE JS-0518-XX High Voltage wire - 24"
17 WIRING KIT JW-SCXX-HX Wiring Harness
18 FLANGE GASKET JS-0591-XX Flange Adapter Gasket
19 SIGHT GLASS KIT JS-0536-XX Sight Glass Kit
20 IGNITER KIT JA-0571KT Igniter & Gasket Kit - DSI Tube Heater
21 NUTS & BOLTS JS-0527-AX 5/16" Bolt and Nuts - Burner to Tube Flange
22 NUT HEX WASHER JF-5618-NW Nut Hex "K-Lok" 5/16" - 18 Washer
23 FLANGED ADAPTER JS-0501-ZZ Flanged Adapter 4" 60-155
24 EYE BOLT JF-1012-EB Eye Bolt
25 CONNECTOR JW-0875-WP Connector-Liquid Tight
26 OPTIONAL FRESH AIR INTAKE CAP JS-0532-VC Fresh Air Intake Cap - OPTIONAL
27 BURNER HEAD JS-0510-LP Burner Head 60 - 80 60 - 80
BURNER HEAD JS-0512-XX Burner Head 110-155 110 - 155
28 AIR RESTRICTOR RING JS-0596-XX Burner Cup Air Restrictor Ring .375 60LP, 60-155NG
AIR RESTRICTOR RING JS-0597-XX Burner Cup Air Restrictor Ring .500 80-155 LP
29 GAS ORIFICE JS-0742-DM Gas Orifice Low Intensity Heater 42 DMS 60 LP
GAS ORIFICE JS-0725-DM Gas Orifice Low Intensity Heater 25 DMS 60 NG
GAS ORIFICE JS-0736-DM Gas Orifice Low Intensity Heater 36 DMS 80 LP
GAS ORIFICE JS-0718-DM Gas Orifice Low Intensity Heater 18 DMS 80 NG
GAS ORIFICE JS-0731DM Gas Orifice Low Intensity Heater 31 DMS 110 LP
GAS ORIFICE JS-0752-MM Gas Orifice Low Intensity Heater 5.2 MM 110 NG
GAS ORIFICE JS-0729-DM Gas Orifice Low Intensity Heater 29 DMS 130 LP
GAS ORIFICE JS-0758-DM Gas Orifice Low Intensity Heater 5.8 MM 130 NG
GAS ORIFICE JS-0714-IN Gas Orifice Low Intensity Heater 9/64 INCH 155 LP
GAS ORIFICE JS-0725-IN Gas Orifice Low Intensity Heater 1/4 INCH 155 NG
30 NUTS & BOLTS JF-8X32-HN Nuts & Bolts - 8/32
31 BURNER CHAMBER JS-0504-XX Outer Burner Assembly
32 EQUALIZER PLATE GASKET JV-0005-XX Equalizer Plate Gasket - Fibrefrax
33 EQUALIZER PLATE JV-2520-XX Plate Equalizer Inlet
VACUUM PUMP & TUBE SYSTEM - Following Pages
