Turbulators – Schwank STSV User Manual
Page 46

46
STV-JZ I&O Manual
IM090512
RD: MAY 2009
RL: 08A- BA
MODEL
TURBULATOR LENGTH
(IF REQUIRED)
STV-JZ 155-60
not required
STV-JZ 155-50
not required
STV-JZ 130-50
not required
STV-JZ 130-40
10' (3 m)
STV-JZ 110-50
not required
STV-JZ 110-40
10' (3 m)
STV-JZ 80-40
10’ (3 m)
STV-JZ 80-30
14' (4.3 m)
STV-JZ 60-30
14' (4.3 m)
STV-JZ 60-20
14' (4.3 m)
NOTE: Improper location of a turbulator can cause malfunction of the heater,
property damage, and will void the heater warranty.
Tube Heaters are supplied with all required turbulator(s) factory installed into
the tube(s). Tubes with turbulators are installed at the vent end of the system
configuration and are clearly labeled for easy identification.
27.
TURBULATORS:
