20
TSD 5 (Only use this instruction if all sources of malfunction
have been eliminated according to TSD 4.)
The latch is touching the cover of the recoil
mechanism. With the ignition on, the rear tail strap
cannot be uncoiled.
Ignition is
turned on?
Vehicle is on
level ground?
Recoil
mechanism
moving freely?
Turn ignition
on.
Belt can be
uncoiled?
Move vehicle
to level ground.
Repeat above
instructions.
With the ignition on, vigorously pull the tail strap 1"-1½" out
of the recoil mechanism.
If necessary put a srewdriver through the hole in the latch in
order to have a better grip.
Now slowly recoil the pulled out belt.
The locking mechanism should release with this manoeuvre.
Belt can be
uncoiled?
Belt can be
uncoiled?
yes
yes
yes
yes
yes
no
no
no
no
no
END
Send retractor
to importer for
inspection.
no
INSTALLATION ACCESSORIES
Color key:
black=0, blue=1, red=2, yellow=3, purple=5, green=8
The X in PINs must be substituted by the color key of the color you want to order!
Shoulder belt pads, pair of
black with yellow flock printing 00109
Shoulder belt pads, pair of blue with black flock printing 01109
red, yellow, purple, green with black flock printing 0X109
Shoulder belt pads, pair of black with grey flock printing 09109
Shoulder belt pads, pair of silvergrey w. black flock printing 09209
Shoulder belt pads, pair of black with black flock printing 09309
Adjusting grips for length adjuster, 4 pcs./package 00092
"Switch off" for manual lock of inertia reel 00096
SPARE PARTS
Adapter for installation at anchor point "D"
01103
(refers to index Y) of Certified Vehicle List (Vehicle Reference List))
Retractor with webbing black 01170
blue, red, yellow, purple, multicolor 0117X
Side belt black 01120
blue, red, yellow, purple, multicolor 0112X
Sensor including installation kit 01090
Wire kit including fuse 00098
Installation kit for harness belt
(w/o Sensor incl. installation kit and wire kit incl. fuse) 01097
Cover for adjuster inclusive retainer 01084
Slide cover and spring for separation buckle 00087
Operating- and Installation Instructions EA 4.3
Transparent interior sticker W26ST
