10
SPECIFICATIONS
AUGER
12 FT. 14 FT. 16 FT.
Drive Type
Chain final drive
Overload Protection
Hydraulic motor
Auger Type
20 in. (508 mm) diameter
variable pitch, center feed
Auger Speed
245 RPM *
CONDITIONER ROLLS
Drive Type
Drivelines from enclosed oil bath chain drive
Roll Type
Helical intermeshing steel “V” bars
Roll Diameter
8.75 in. (222 mm)
Roll Length
93 in. (2360 mm)
Roll Speed
827 RPM *
WHEELS
Tread Width
119 in. (3030 mm) 143 in. (3640 mm) 143 in. (3640 mm)
Tires
31 x 13.5 - 15 NHS 8 ply Terra-Rib
Tire Pressure
30 psi (207 kPa)
MATERIAL DISCHARGE
Minimum Width
30 in. (760 mm)
Maximum Width
92 in. (2346 mm)
Rear Fluffing Shield
Adjustable
OPERATING SPEED
Recommended Field Speed
5 mph (8 km/h)
Recommended Transport Speed
20 mph (30 km/h)
TRACTOR REQUIREMENTS
Minimum Power
60 hp (45 kw) 75 hp (56 kw) 90 hp (68 kw)
Drawbar Capacity Must Exceed 1300 lbs. (5785 N) 1030 lbs. (4580 N) 1100 lbs. (4895 N)
PTO 540 or 1000 RPM - ASAE standard location
Hydraulic Capacity 1750 psi (12000 kPa), two hydraulic circuits
* All speeds are in no-load condition at rated tractor RPM.
(SPECIFICATIONS AND DESIGN ARE SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION TO
REVISE UNITS PREVIOUSLY SOLD.)
