Page 5
4
Type 2 - Modified distributor (to serve as the cam sync) to be used with a crank trigger
setup
The cam sync drive provides a signal (every 360
o
of cam rotation) that allows for cylinder “fuel-
phasing” (controlling the point, BTDC, when the fuel is injected into the cylinder) and individual
cylinder “timing control”.
The cam sync signal, references the start of an injection or ignition firing sequence, and needs to occur
10
o
- 20
o
before the crank signal. The cam sync signal informs the ECU of the position of the number 1
cylinder. After the cam sync signal, the next input received by the ECU is the crank signal from the
crank trigger.
Quick Setup Guide
• If applicable, lock out the centrifugal advance. See
on page
3.
• Find TDC, cylinder number one (1), compression stroke. See
• Roll the engine back to 50
o
Measuring_Distances_on_the_Dampener
• Install the crank trigger. Line up the sensor with the magnet. make sure the arrows on the
crank trigger wheel are going on the correct direction! See
on
page 21.
• Connect the crank trigger green wire to the BigStuff3 red wire. Connect the other crank trigger
wire to BigStuff3 black wire.
• Roll the engine back to 70
o
BTDC cylinder number 1 compression
• Install the distributor and make sure it is fully seated by “bumping” the starter until it engages
the oil pump drive while applying a light downward pressure.
• Line up the reluctor that is closest to the pole piece and mark it with permanent marker.
Remove the seven other reluctors. See
• Re-install the modified distributor, making sure the remaining reluctor is aligned with pole
piece.
• Tighten down the distributor
• Roll the engine back to the position BTDC (cylinder 1) equal to the ignition timing the engine
will see at maximum power.
• Phase the rotor and/or reluctor. See
• Connect the
red
BigStuff3 wire to the
violet
/black striped MSD distributor wire. Connect
other Distributor wire to BigStuff3 black wire. See
on page 6.
• Connect the BigStuff3 points wire (white) to the MSD ignition box points input.
• In the BigComm Software (Operating Configuration), set the crank reference setting to 50. See
• Start the engine.
• Use the “CamCrkAdv” window in the Dash to adjust the cam sync to 15
o
- 20
o
. This is the
number of crank shaft degrees that the cam sync pulse occurs before the crank pulse. Loosen
and adjust the cam sync (modified distributor) until the cam sync occurs at least 15
o
- 20
o
before
the crank.
Re-tighten the cam sync (modified distributor). See
• Lastly, with the engine still running verify that the BigStuff3 “Dash” timing advance value
equals the timing value seen (with a timing light) at the crank. Change the crank reference
