Setting up the 830 as a transmitter

Configure your 830 to the same Span (URV) and Zero (LRV) by
storing Span & Zero setting with the

q

EZ-CHECK switch.

1) Store your SPAN input by moving the

q

EZ-CHECK switch

to the

MAX position and turning the

e

EZ-Dial knob until the

desired output value is on the display. Press and hold the
EZ-Dial knob until

STORED appears to store the value.

Release the EZ-Dial knob.

2) Store your ZERO input by moving the EZ-CHECK switch to

the

MIN position and turning the EZ-Dial knob until the

desired output value is on the display. Press and hold the
EZ-Dial knob until

STORED appears to store the value.

Release the EZ-Dial knob.

3) Move the EZ-CHECK switch to the

READ position. The 830

constantly measures the input from the process sensor and
regulates the current in the 4-20 mA loop.

Once the PIE 830 is setup and connected to the process sensor
and the 4-20 mA loop it acts just like a calibrated isolated transmitter
and will display the input signal from the sensor and the regulated
4-20 mA output signal. XMTR is shown on the display along with L,
N or S for Linear, Nonlinear or Square Root respectively.

12.000 mA

SUPPLY

23.4 V

LOAD

987 Ω

500.0

°c

TYPE K

XMTRL
12.000 mA

500.0

°c

TYPE K

For full loop diagnostics turn on LOOPSCOPE which indicates
the current, SUPPLY (voltage) and LOAD (resistance) of the
loop. It also indicates errors by flashing the LED and writing
diagnostic messages including

LOW LOOP VOLT, HIGH LOOP

VOLT and HIGH LOOP IMPED.

830 as Transmitter

830 with LOOPSCOPE
