Ins-187 Net2 Desktop reader (1999)
Cable extensions
The reader comes with 3 metres of cable. Readers can be extended using Belden CR9540 10-core overall
screened cable. The maximum between reader and controller is 50 metres.
Suitability
Wiring
Green
White/Green 1
Screen or spare cores from
network cable
White/O rang e 3
Orang e 4
K
R
1 re
da
e
da
py
e
1
R
lea y
2
R
lea
y 1
Keypad 2 Reader 2
st
up
nI
P
e wo
r
C A
ni do
c el
ba
c
5T
g
kr
o wt
e N
Net2 classic
2
Red 12V dc
Red LED
Amber LED
Green LED
Data/D0
Clock/D1
Media Detect
0V out
Load
Data
Clock
R
cd
V2
1
de
R
DE
L
de
DE
L re
b m A
DE
L
ne
er
G
0 D/
at
a D
1 D/
kc
ol
C
tc
et e D
ai de
M
tu
o
V0
da
oL
at
a D
kc
ol
C
+12V
0V
T
F :n
oit
ua
C
ro
yl no
sr
ed
ae
r
c. d
V2
1
.
F
tc
er ro
c ro
no it
ce
nn
oc
fo
fe
r sr
ed
ae
r
V5
dl o
re
ot
sn
oit
cu
rt
sn i
PLACE SERIAL
NUMBER
LABEL HERE
http://paxton.info/107
123456
0889
Setting up the Desktop Reader function
To configure a door reader to operate as a Desktop Reader:
- Run the Net2 software / Log In.
- Select the Doors menu in the left hand pane.
- Click on the door you wish to act as a desktop reader.
- Select the relevant reader tab and change the reader operating mode to ‘Desktop Reader’
- The PC displays ‘Would you like to accept desktop reader events from this reader at the PC?’; click ‘Yes’
The door reader will now act as a Desktop Reader, enabling you to add new tokens or edit existing ones.
KP Reader - First set the keypad type to ‘None’, or the Desktop Reader option will not be available.
The reader is designed to work with a Net2 ACU and must be connected to a spare reader port. This ACU will
therefore not be available for both read-in and read-out operation.
If no free port is available, a dedicated ACU will be required for the desktop reader.
All Paxton Access Ltd proximity tokens and Magstripe cards will work with this reader. They include the proximity
card, proximity keyfob, proximity ISO card and the magstripe card.
The reader is intended for internal desktop use only.
