Paxton PROXIMITY architectural reader - Manual (Page 4)

10V DC 14V DC
140 mA
125 kHz
600 µs
-20 °C +55 °C
IPX7
70 mm 110 mm 10 mm
60 mm 100 mm 25 mm
40 mm 25 mm 400 mm
The declaration of conformity is available on request. Contact details are provided at: http://paxton.info/596
Voltage
Clock and data bit period
Carrier frequency
Specifications
Operating temperatures - all items
Electrical
Environment
Dimensions
Min Max
Depth Width
Current
Cable length
Read Range Token Keyfob Hands Free Token
Waterproof
Min Max
Height
Reader
Backbox
PROXIMITY architectural reader
Backbox assembly
Reader insert diagram
Instruction set
Kit fk1-080 4 No 8 x 1in pozi pan self tapping screw - zinc
4 35mm wall plugs
3 M3 x 10 nylon screw
1 Reader removal tool
Contents in box
Description Qty Fitting kit
This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.
5 metres
