Paxton OEM Magstripe reader, Wiegand 26 bit output - Manual (Page 2)

The 26 Bit Wiegand standard is defined as follows;
PSSSSSSSSUUUUUUUUUUUUUUUUP
P= Parity bit
S= Site Code
U= User Code
The first Parity bit is a 1 if it is required to make the total number of bits 1-13 an Even number.
The last Parity bit is a 1 if it is required to make the total number of bits 14-26 an Odd number.
Special cards may be used which comprise a start sentinel followed by 3 digits, a field separator, a further 5 digits
and an end sentinel.
The 3 digits preceding the field separator (=) are taken as the site code and the 5 digits after the field separator
are taken as user code.
Example: - SS 152=27854 ES
Site code : 152 = 10011000 (Binary)
User code: 27854 = 0110110011001110 (Binary)
Accepted token data formats.
ABA standard cards
The data on ABA standard cards comprise a start sentinel followed by 16 digits, a field separator and some
additional characters.
Only the 6 digits before the field separator (=) are used and are transmitted to the controller.
Example: SS 1234567898 765432 = 1478 5236 ES LR
The data (6 digits before =) is therefore 765432
The first 2 digits are then used as the site code and the remaining 4 digits become the user code.
Site Code: 76 01001100 (Binary)
User Code: 5432 0001010100111000 (Binary)
Voltage
Wiegand format
Reader head life
-20 °C +55 °C
5 metres
IPX7
1,000,000
8V DC 14V DC
90 mA 110 mA
26 bits
125 mm/s 1250 mm/s
500 mm/s 2
300 Oe 4000 Oe
34mm 89mm 34mm
Specifications
Electrical
Environment
Dimensions
Min Max
Width Height Depth
Current
Operating temperature
Cable length
Reader
IP Rating Outdoor Use
Swipes
Media speed
Media acceleration
Magnetic stripe coercivity
