Krone terminal strip
Net2 data cable
White/Green
Green
White/Orange
Orange
White/Brown
Blue
Brown
White/Blue
SCREEN
Net2 data cable
The unit is not dependant on the direction of the data flow. Ensure that the Green and Orange data
pairs match the correct colour positions. The Brown and Blue pair positions are grouped into a
common Screen connection.
A Krone insertion tool (not supplied) should be used to ensure a good connection of the wires into the
terminal strip.
How to fit the module
