Paxton OEM hands free keyfob - Manual

05/01/2010
Suitability
Compatible with hands free readers Compatible with non hands free readers
28 mm
12 mm
49 mm
125 kHz
2.4 GHz
0 °C 55 °C
CR2032
P38 850 mm
P50 1100mm
P75 1500 mm
P200 2500 mm
2000 mm
5000 mm
Specifications
Carrier frequency
Operating temperature - Battery limits
Environment
Dimensions
Min Max
Width
Height
Length
P200E metal mount
Read range with hands free token
System Specification
Typical Battery Life
Battery Type 3 years
Long range reader
Remove the small retaining screw. Insert a flat head screw driver into the groove in the corner below the screw
position (see diagram) and gently twist to prise the case open.
Replace the battery, clip the cover closed and secure with the retaining screw.
Battery replacement
The keyfob has been designed with features to extend battery life. This includes the prevention of repeated
access requests to the same door whilst the keyfob remains within range. However, keeping the keyfob in the
field of a reader can still reduce battery life to 12 months or less.
SAFETY WARNING
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
- EM 4100
Ins-30052 OEM hands free keyfob
