Paxton Net2Air USB bridge User Manual
Paxton, Technical support, Net2air wireless communication

Ins-30084 Net2Air USB bridge
18/04/2013
Technical Support
Technical help is available: Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
01273 811011
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
The access control unit connects to the Net2 system using Paxton Net2Air proprietary wireless technology through
a Net2Air bridge.
Radio signals do not always behave as you might expect. For example, a mobile phone that displays a full signal
on one part of the site will lose signal completely only a few metres away.
See also:
X
AN1095 - Net2 wireless access control - How does it work? < http://paxton.info/974 >
X
AN1096 - How to plan a Net2 wireless installation < http://paxton.info/975 >
Net2Air wireless communication
Plug the device into a spare USB port on the PC. Restarting the Net2 server will then register the unit automatically
in the Net2 software. This displays in the Net2 Server Configuration Utility/Net2Air bridge as a fixed IP.
Reader
Control unit
Net2Air USB bridge
Net2
Server
Software Configuration
Paxton
3m
15m
20m
30m
0
Range
With reference to the diagram, the unit should be located at a distance as shown within the Green area.
Performance may be reduced with an increase in distance as shown by the Amber area.
The unit should not be used at distances shown by the Red areas.
Software - Requires Net2 v4.14 or later.
