Paxton PROXIMITY vandal proof reader - Manual (Page 4)

10V DC 14V DC
110 mA
125 kHz
600 µs
-20 °C +55 °C
IPX7
20 mm 60 mm
80 mm 40 mm
PROXIMITY vandal proof reader
Documentation
Fitting Kit VP Covers fk1-043 1 M20 Proximity cover, Black
1 M20 Proximity cover, White
Fitting Kit VP Reader fk1-044 2 No 6 x 3/4in countersunk BZP self tapping screw
2 22 mm Wall Plugs
5 Cable clips
1 M20 Proximity mounting plate, Black
Contents in box
Description Option Qty
The declaration of conformity is available on request. Contact details are provided at: http://paxton.info/596
Voltage
Clock and data bit period
Carrier frequency
Specifications
Operating temperatures - all items
Electrical
Environment
Dimensions
Min Max
Current
Cable length
Read Range Token Keyfob Hands Free Token
Waterproof
Min Max
This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person.
Outdoor Use
Diameter Depth
Not Compatible
5 metres
