DCA-85SSJU — LOAD APPLICATION
Single Phase Load
Always be sure to check the nameplate on the generator
and equipment to insure the wattage, amperage and
frequency requirements are satisfactorily supplied by the
generator for operating the equipment.
Generally, the wattage listed on the nameplate of the
equipment is its rated output. Equipment may require 130—
150% more wattage than the rating on the nameplate, as
the wattage is influenced by the efficiency, power factor and
starting system of the equipment.
Motors and motor-driven equipment
draw much greater current for starting
than during operation.
An inadequate size connecting cable
which cannot carry the required load can cause a voltage
drop which can burn out the appliance or tool and overheat
the cable.
When connecting a resistance load such as an
incandescent lamp or electric heater, a capacity of up
to the generating set’s rated output (kW) can be used.
When connecting a fluorescent or mercury lamp, a
capacity of up to the generating set’s rated output (kW)
multiplied by 0.6 can be used.
When connecting an electric drill or other power tools,
pay close attention to the required starting current
capacity.
When connecting ordinary power tools, a capacity of up to
the generating set’s rated output (kW) multiplied by 0.8 can
be used.
d
a
o
L
y
B
r
o
t
c
a
F
r
e
w
o
P
.
4
1
e
l
b
a
T
d
a
o
L
f
O
e
p
y
T
r
o
t
c
a
F
r
e
w
o
P
s
r
o
t
o
m
n
o
i
t
c
u
d
n
i
e
s
a
h
p
-
e
l
g
n
i
S
5
7
.
0
-
4
.
0
t
n
e
c
s
e
d
n
a
c
n
i
,
s
r
e
t
a
e
h
c
i
r
t
c
e
l
E
s
p
m
a
l
0
.
1
s
p
m
a
l
y
r
u
c
r
e
m
,
s
p
m
a
l
t
n
e
c
s
e
r
o
u
l
F
9
.
0
-
4
.
0
n
o
i
t
a
c
i
n
u
m
m
o
c
,
s
e
c
i
v
e
d
c
i
n
o
r
t
c
e
l
E
t
n
e
m
p
i
u
q
e
0
.
1
s
l
o
o
t
r
e
w
o
p
n
o
m
m
o
C
8
.
0
NOTE
If wattage is not given on the
equipment's name plate, approximate
wattage may be determined by
multiplying nameplate voltage by the
nameplate amperage.
WATTS = VOLTAGE x AMPERAGE
The power factor of this generator is 0.8. See Table 14
below when connecting loads.
Before connecting this generator to any
building’s electrical system, a licensed
electrician must install an isolation
(transfer) switch. Serious injury or death
may result without this transfer switch.
CAUTION:
Three Phase Load
When calculating the power requirements for 3-phase power
use the following equation:
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION:
NOTE
If output (kVA) is not given on the equipment
nameplate, approximate output may be
determined by multiplying voltage by
amperage by 1.732.
