DCA-60SSAI — PARTS AND OPERATION MANUAL— FINAL COPY (09/15/01) — PAGE 89
ENCLOSURE ASSY.
DCA-60SSAI --- ENCLOSURE ASSY.
NO. PART NO. ITEM QTY. REMARKS
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO
INDICATE COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
37 7455141102 REAR FRAME 1 ............UP TO S/N3311616
7455141112 REAR FRAME 1 ............S/N3312178~
38 7455109603 ACOUSTIC SHEET 1
39 7450630904 STRIPE 2
40 0017108020 HEX. HEAD BOLT 4
41 7455155003 COVER, REAR FRAME 1
42 7455109703 ACOUSTIC SHEET 1
43 0041608000 PLAIN WASHER 8
44 0040008000 LOCK WASHER 8
45 0010008040 HEX. HEAD BOLT 8
46 7455143103 DOOR, REAR FRAME 1 ............UP TO S/N3311616
7455143113 DOOR, REAR FRAME 1 ............S/N3312178~
47 1320632003 STICKER 1
48 3805147104 WINDOW PLATE 1
49 0021006020 MACHINE SCREW 6
50 0041606000 PLAIN WASHER 6
51 0040006000 LOCK WASHER 6
52 0030006000 HEX. NUT 6
53 0845028303 HINGE 2
54 0017108025 HEX. HEAD BOLT 4
55 7455161012 ROOF PANEL 1
56 7455109803 ACOUSTIC SHEET 1
57 0017108020 HEX. HEAD BOLT 16
58 7455165004 GUIDE PANEL, AIR 2
59 7455109904 ACOUSTIC SHEET 2
60 0017108020 HEX. HEAD BOLT 8
61 7455181202 SPLASHER PANEL 1 ............UP TO S/N3312672
7455181212 SPLASHER PANEL 1 ............S/N3312673~
62 7455105004 ACOUSTIC SHEET 1
63 0010008055 HEX. HEAD BOLT 6
64 0040008000 LOCK WASHER 6
65 001608000 PLAIN WASHER 6
