DCA-60SSAI — PARTS AND OPERATION MANUAL— FINAL COPY (09/15/01) — PAGE 33

DCA-60SSAI — OUTPUT TERMINAL VOLTAGE SELECTION

DCA-60SSAI

Legs O and Ground are
considered Bonded Grounds.

NOTE

Figure 12. Output Panel Location
