DCA70SSIU 50 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (01/06/09) — PAGE 65
OUTPUT TERMINAL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M3230700003 TERMINAL PANEL 1
2 M3278500004 OUTPUT TERMINAL BOLT 5
3 0801830904 TIE BOLT 5
4 0040020000 WASHER, LOCK 5
5 0041420000 WASHER, FLAT 5
6 0039316000 HEX NUT 10
7 0040016000 WASHER, LOCK 10
8 0041416000 WASHER, FLAT 15
9 0016908035 HEX HEAD BOLT 5
10 M2238100003 TERMINAL COVER 1
11 M3236100104 OUTPUT WINDOW 1
12 0605010040 HINGE 2
13 0027103010 MACHINE SCREW 4
13A 0030003000 HEX NUT 4
13B 0041203000 WASHER, FLAT 4
14 0027103010 MACHINE SCREW 4
14A 0030003000 HEX NUT 4
15 0016906020 HEX HEAD BOLT 2
16 0016906016 HEX HEAD BOLT 4
17 M3236400004 CABLE OUTLET COVER 1
18 M3236300004 CABLE OUTLET COVER SUPPORTER 1
19 0016906020 HEX HEAD BOLT 6
20 0601870440 CIRCUIT BREAKER- QCF 1020 1P 20A 2
21 0601870441 CIRCUIT BREAKER- QCF 2050 2P 50A 3
22 M1260700504 BREAKER FITTING COVER 1
22-1 0222100100 CUSHION RUBBER 2
23 0016906020 HEX HEAD BOLT 2
24 0601812598 RECEPTACLE - GF530EM 125V 20A X 2 2
25 0601812538 RECEPTACLE - CS6369 250V 50A 3
26 0027104016 MACHINE SCREW 10
26A 0207004000 HEX NUT 10
27 0603306775 BLIND PLUG 2
28 0027104016 MACHINE SCREW 4
29 0601815194 TERMINAL - 601-GP-02 1
30 0027104016 MACHINE SCREW 2
31 M2455400003 TERMINAL COVER 1
32 0010112045 HEX HEAD BOLT 2
33 0041212000 WASHER, FLAT 2
34 M9310200004 STAY RUBBER 2
35 0030012000 HEX NUT 2
