DCA70SSIU 50 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (01/06/09) — PAGE 55
GENERATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 B5110000102 ROTOR ASSY. .............................................1 ................INCLUDES ITEMS W/*
1-1* FIELD ASSY. 1
1-2* 8101070033 FAN 1
1-3* 0010310035 HEX HEAD BOLT 8
1-4* 0042510000 WASHER, LOCK 8
1-5* 8101611004 COUPLING DISK 5
1-6* 8101015003 BALANCING PLATE ....................................1 ................PURCHASE SET OF 1-16
1-7* 0012110030 HEX HEAD BOLT ........................................8 ................S=26
1-8* 0042510000 WASHER, LOCK 8
1-9* 8101026013 SET PLATE, RECTIFIER.............................1 ................PURCHASE SET OF 1-16
1-10* 0601821349 RECTIFIER .................................................2 ................PT3610
1-11* 0601822601 SURGE ABSORBER ...................................1 ................ERZ-M14JK621A
1-12* 8001020004 INSULATOR WASHER 1
1-13* 8001020504 INSULATOR WASHER 1
1-14* 0010110020 HEX HEAD BOLT 4
1-15* 0040010000 WASHER, LOCK 4
1-16* 0601000209 BALANCING WEIGHT KIT 1
1-17* 0071906311 BEARING ....................................................1 ................6311DDU C3
2 M2163400103 COUPLING RING 1
3 M9200100204 REAMER BOLT 2
4 0010310030 HEX HEAD BOLT 7
5 0042510000 WASHER, LOCK 9
6 B5130000103 STATOR ASSY ............................................1 ................B5134000304
7 0845041904 GROMMET 2
8 8191315292 END BRACKET 1
9 8101350013 FIELD ASSY EXCITER ...............................1 ................B5134000304
10 0012110070 HEX HEAD BOLT ........................................4 ................S=26
11 0042610000 WASHER, LOCK 4
12 0041210000 WASHER, FLAT 4
13 0017110035 HEX HEAD BOLT 6
14 8101312014 COVER, BEARING 1
15 8131312014 GASKET, BEARING 1
16 0016906016 HEX HEAD BOLT 4
17 8101331003 COVER, END BRACKET 1
18 0016906016 HEX HEAD BOLT 4
19 8101333003 COVER, END BRACKET 1
20 0340406040 HEX HEAD BOLT 1
21 0041606000 WASHER, FLAT 1
22 0010110030 HEX HEAD BOLT 12
23 0042510000 WASHER, LOCK 12
24 8111332014 COVER, FAN 1
25 0340406040 HEX HEAD BOLT 1
26 0041606000 WASHER, FLAT 1
27 0600815000 NUT 1
28 0605000010 RUBBER SUSPENSION 2
29 0030012000 HEX NUT 2
29A 0040012000 WASHER, LOCK 2
29B 0041212000 WASHER, FLAT 2
