DCA70SSIU 50 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #1 (01/06/09) — PAGE 17
MAJOR COMPONENTS
Generator Major Components
Table 4.
ITEM NO.
DESCRIPTION
1
Output Terminal Panel Assembly
2
Output Receptacles Assembly
3
Air Filter Assembly
4
Muffl er Assembly
5
Fuel Assembly
6
Engine Assembly
7
Battery Assembly
8
Generator Assembly
9
Generator Control Panel Assembly
10
Engine Control Panel Assembly
Major Components
Figure 3.
