page 12 — dCa20spxu2 servpro ® • operation and parts manual — rev. #0 (09/23/13)
table 1. generator specifications
model DCA-20SPXU2
type Revolving field, self ventilated, open protected type synchronous generator
armature Connection Series
phase Single-Phase 3-Wire
standby output 22 kW (27.5 kVA)
prime output 20 kW (25.0 kVA)
Voltage 120/240V
Frequency 60 Hz
speed 1800 rpm
Power Factor 1.0
aux. aC power Single Phase, 60 Hz
sound level db (a) full load
at 23 ft. (7 meters)
63
Weight (no Fuel) 1,412 lbs. (640 kg.)
Weight (Fuel) 2,012 lbs. (913 kg.)
table 2. engine specifications
model ISUZU BV-4LE2 Tier 4i
type 4 cycle, water-cooled, direct injection, turbo-charged
no. of Cylinders 4 cylinders
Bore x stroke 3.34 in. x 3.77 in. (85 mm x 96 mm)
displacement 133 cu. in. (2,179 cc)
rated output 34.3 HP/1800 RPM
Starting Electric
Coolant Capacity 1.74 gal. (6.6 liters)
lube oil Capacity 2.25 gal. (8.5 liters)
Fuel type #2 Diesel Fuel, Low Sulfur Diesel Fuel Only
Fuel tank Capacity 17 gal. (65 liters - Internal) 41 gal (155 liters External)
Fuel Consumption
1.66 gal. (6.3 L)/hr at full load 1.21 gal. (4.6 L)/hr at 3/4 load
0.85 gal. (3.2 L)/hr at 1/2 load 0.58 gal. (2.2 L)/hr at 1/4 load
Battery 12V 53Ah x 1
table 3. trailer specifications
model TRLR50XF
gross vehicle Weight rating 2,700 lbs. (1,225 kg)
gross axle Weight rating 3,500 lbs. (1,588)
axle/suspension Single/Leaf Spring
tire load rating 1,360 lbs. (617 kg ea.)
Wheel Bolt Pattern 5 Lug on 4.5 in.
tongue mounted swivel Jack 1,000 lbs. (454 kg) Lift Capacity
Coupler options Adjustable 2"or 2-5/16" Ball and 3" Pintle Eye
lights DOT approved Tail, Stop, Turn, License Lights
Weight 510 lbs. (231.5 kg) No Fuel/801 lbs. (363.6 kg) With Fuel
specificatiOns
