SP2S13H20A SAW — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 87
CYLINDER BARREL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 12000ZF6W13 CYLINDER ASSY. (ALERT) ....................... 1 ......... INCLUDES ITEMS W/ *
2 15510ZE2043 SWITCH ASSY., OIL LEVEL 1
4 16541ZE3010 SHAFT, GOVERNOR ARM 1
9 90131896650 BOLT, DRAIN PLUG 2
10 90446KE1000 WASHER (8.2X17X0.8) 1
12 * 91201ZE3004 OIL SEAL (35X52X8) 1
13 * 91201ZE9003 OIL SEAL (8X14X5) 1
14 91353671003 O-RING (13.5X1.5) (ARAI) 1
17 9405010000 NUT, FLANGE (10MM) 1
18 9410912000 WASHER, DRAIN PLUG (12MM) 2
19 9425110000 PIN, LOCK (10MM) 1
20 957010601200 BOLT, FLANGE (6X12) 2
21 * 961006202000 BEARING, RADIAL BALL (6202) 1
22 34150ZH7003 ALERT UNIT, OIL 1
23 90013883000 BOLT, FLANGE (6X12) (CT200) 1
HONDA GX390K1QWT2 ENGINE — CYLINDER BARREL ASSY.
